Rotary Drum Screen

Rotary Drum Screen filter is a mechanical filtration equipment, including transmission device, water distributor, water spraying device and other major components. The rotating drum screen is made of stainless steel. The working principle is that the treated water enters the water distributor from the inlet, after a short period of steady flow, it evenly overflows from the outlet and distributes on the rotary drum screener that rotates in the opposite direction. Due to the relative shearing motion generated by the water flow and the inner wall of the rotary drum screens, the solid is retained and separated, and tumbles by the spiral guiding plate and discharges from the other end of the Rotary drum screen; And directed by the protection cover, the filtered waste water flows out from the underneath sink.

The frame of the Rotary Drum Screening filter is equipped with flushing water pipe, and is sprayed with pressure water (3Kg/m²) in a fan-shaped manner to flush and dredge the Rotary drum screen, so as to ensure good filtering capability.

rotary drum screen

Rotating Drum Screen

Rotating Drum Screen is an internally fed screening device with the flow being fed and distributed inside a screening cylinder. It is widely used for separation of settleable solids from liquid in municipal and industrial wastewater treatment plant.

Rotating Drum Screen can be designed to open type or fully covered type according to the onsite working condition.



rotary drum screem

Externally Fed Rotary Drum Screen

The Externally Fed Drum Screen is designed for small and medium-sized wastewater treatment plants. It’s aiming at screening the floating solid substances in the water and widely used in wastewater pretreatment and industrial screening. 30% to 60% of the organic and inorganic floating solid substances will be removed after filtering which will greatly reduce the working load of the following process.



rotary drum filter

Rotary Drum Filter

Rotary Drum Filter is an internally fed screening device with the flow being fed and distributed inside a screening cylinder. It is widely used for separation of settleable solids from liquid in municipal and industrial wastewater treatment plant.

Rotary Drum Filter can be designed to open type or fully covered type according to the onsite working condition.



channel drum screens

Channel Drum Screens

Channel Drum Screens are widely used in wastewater treatment of municipal wastewater, industrial wastewater, food processing industry, paper making industry, ect. This equipment can remove the scum, short fiber and suspended solids from the water intake and then discharge them after pressing. Rotary Drum Fine Screen



rotary vacuum drum filter

Rotary Vacuum Drum Filter

Rotary Vacuum Drum Filters provide a wide range of liquid-solids separation for many types of industrial processing flow sheets. They offer the operating flexibility to handle dewatering, washing and clarification applications, or a combination of the two.
